ASTM Standard Q195 Wire Nail Making Machine High Plasticity

1 Ton
MOQ
to be negotiated
Price
ASTM Standard Q195 Wire Nail Making Machine High Plasticity
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Steel Wire For Nail, Rivet, Screw Production
Steel Grade: Steel
Application: Construction
Special Use: Free Cutting Steel
Processing Service: Welding, Decoiling, Cutting
Standard: ASTM, BS, DIN, JIS
Type: Drawn Wire
Alloy Or Not: Non-Alloy
Model Number: Q195, #45, SAE1022, Etc
Grade: Steel Wire
High Light:

ASTM Standard Wire Nail Making Machine

,

Q195 Wire Nail Making Machine

,

ASTM Wire Nail Making equipment

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: DURA
Certification: CE
Model Number: 1mm; 1.2mm; 1.5mm; 2mm; 1.8mm; 2.5mm; 3mm; 5mm; 0.8mm; 0.6mm
Payment & Shipping Terms
Packaging Details: Nude Package, Plywood Case
Delivery Time: 1-25 Tons/15 Days; >25 To Be Negotiated
Payment Terms: L/C, D/P, T/T
Supply Ability: 1000 Tons per Month
Product Description

Steel Wire for Nail, Rivet, Screw Production



Q195:
C≤0.12 Si≤0.30 S≤0.040 Mn≤0.50 P≤0.035
Tensile strength: 315-430(σb/MPa)
Features: high plasticity, ductility, welding performance and good pressure processing performance
Material code of different system corresponding to GB/T 700: Q195 - ASTM: Gr.B(σs185) - ISO: HR2(σs195) - гOCT: CT1Kп - JIS: SS330(SS34)(σs205) - DIN: St33 - BS: 040A10 - NF: A33
Note: the Chinese national standard steel number Q195 stands for "yield strength σs = 195MPa", which is an experimental value measured with a φ16mm steel rod. If the diameter is 16 ~ 40mm steel, the yield limit is 185MPa, which is the nomenclature adopted by ASTM in the United States.
Mechanical properties Elongation(δ5/%):≥33(thickness or diameter≦16mm),≥32(thickness or diameter>16-40mm)
Applications: Used to manufacture anchor bolts, rivets, low-carbon steel wires, tie rods, hooks, brackets, welded structures, etc.The wire rods are mostly cold drawn into low carbon steel wire or made of galvanized low carbon steel wire for tying, tensioning and fixing, or as wire mesh, rivets, etcASTM Standard Q195 Wire Nail Making Machine High Plasticity 0
