Pit Type Electric Annealing Furnace, Heat Treatment for Binding Wire and Other Metal Materials

1 SET
MOQ
to be negotiated
Price
Pit Type Electric Annealing Furnace, Heat Treatment for Binding Wire and Other Metal Materials
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Pit Type Electric Annealing Furnace, Heat Treatment For Binding Wire And Other Metal Materials
Place Of Origin: Jiangsu, China
Warranty: One Year
Model: WAF Series
Type: Pit Type
After-sales Service: Field Installation, Commissioning And Training
Key Selling Points: Competitive Price
High Light:

Pit Type Electric Annealing Furnace

,

Electric Annealing Furnace Heat Treatment

,

Binding Wire Surface Treatment Machine

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: DURA
Certification: CE
Model Number: WAF-75-9; WAF-90-9; WAF-120-9; WAF-65-6; WAF-60-6; WAF-75-6
Payment & Shipping Terms
Packaging Details: Wooden Cases/Pallets, Plywood Cases/Pallets, Steel Pallets, etc.
Delivery Time: 1 Set/45 Days; >1 To Be Negotiated
Payment Terms: L/C, D/P, T/T
Supply Ability: 15 Sets Per Month
Product Description

Pit Type Electric Annealing Furnace, Heat Treatment for Binding Wire and Other Metal Materials



Applications



1. For medium temperature furnace



It is mainly applied to bright annealing or non-bright annealing treatments for steel strips, steel wires, silicon steel sheets, scroll iron cores,

gas-protected welding sticks and other ferrous metal materials.



Model Motor Power(KW) Rated Temperature(°C)

Loading size of pot (mm)

WAF-75-9 75 950 Ø 800 x 1200
WAF-90-9 90 950 Ø 800 x 1500
WAF-120-9 120 950 Ø 1000 x 1500
WAF-150-9 150 950 Ø 1000 x 1800



2. For low temperature furnace



It is mainly applied to bright annealing of copper/Al. wires, copper/Al. strips, copper /Al. pipes, and other nonferrous metal materials.



Model Motor Power(KW) Rated Temperature(°C) Loading size of pot(mm)
WAF-45-6 45 650 Ø 700 x 1200
WAF-60-6 60 650 Ø 800 x 1200
WAF-75-6 75 650 Ø 800 x 1500



Energy-saving firepot



Features

The unique structure of energy-saving furnace pot uses the Cr20Ni80 nickel-chromium alloy resistor strips that are coiled into an M shape to replace the traditional Fe-Cr-A1 resistor wire, so as to increase directional heat radiation to get good energy-saving effect, and the resistor band won’t be broken for three years.

Pit Type Electric Annealing Furnace, Heat Treatment for Binding Wire and Other Metal Materials 0
